Enforcing and proving BitLocker TPM+PIN across an Intune fleet

You’ve decided to require TPM+PIN. We already covered why that’s the call for CVE-2026-45585 (the YellowKey WinRE BitLocker bypass, CVSS 6.8); this post is how you enforce it and prove it landed across the fleet. The short version of the threat: on a TPM-only device, the TPM auto-releases the Volume Master Key at boot, so the WinRE attack reaches an already-decrypted volume. A startup PIN holds the key back until someone types it. The NVD entry confirms TPM+PIN devices aren’t exploitable by the public PoC. That’s where this runbook starts.

The trap is that requiring a PIN is one toggle in Intune, and that toggle does almost nothing on the devices you most need to fix. The work is finding the TPM-only machines, pushing the requirement, dealing with the fact that Intune can require a PIN but can’t set one, and then validating at scale so “we pushed the policy” becomes “we can prove it’s enforced.”

What you’re enforcing

Two states matter per device: BitLocker protection is on, and a TPM+PIN key protector exists. A device can pass the first and fail the second. That’s the common gap. It was encrypted with a bare TPM protector months ago, the new policy says “PIN required,” and the device sits there protected but PIN-free, reporting non-compliant with nothing actually changed at boot.

Push the requirement

Go to Endpoint security > Disk encryption > BitLocker in the Intune admin center (Settings Catalog format since June 2023). On the OS drive, set Compatible TPM startup PIN = Required. The underlying BitLocker CSP node is SystemDrivesRequireStartupAuthentication. Supporting settings:

• Minimum PIN length (SystemDrivesMinimumPINLength, 4-20).
• Enhanced PIN (SystemDrivesEnhancedPIN) if you want alphanumeric.
• Preboot input on slates (SystemDrivesEnablePrebootInputProtectorsOnSlates) for tablets, or they can’t take preboot keyboard input at all.

Now the wall. Per Microsoft, Intune can require a PIN but cannot set one. The CSP enforces startup auth only at the time encryption begins. What that means in practice:

• New or unencrypted device: policy lands, the user is walked through the PIN setup wizard. This case works.
• Already-encrypted TPM-only device (your bulk): the policy updates registry keys, adds no PIN protector, prompts nobody. The device just flips to non-compliant. Nothing is fixed.
• HSTI / Modern Standby devices: the CSP docs say these can’t configure a startup PIN via the CSP at all; users must set it manually. That covers a lot of modern Surface and ultrabook hardware. (Exact behavior on current 24H2/25H2 builds isn’t fully confirmed, so test before you assume.)
• Autopilot / ESP: PIN setup needs a logged-in user, and ESP runs as SYSTEM. It can’t happen there. The community pattern is a Win32 app deployed post-enrollment, sometimes seeding the device serial as a temporary PIN.

For the already-encrypted fleet, you need a script. Add the TPM+PIN protector, then remove the bare TPM protector, or the device still boots PIN-free:

# Add TPM+PIN protector (prompts the user for the PIN value)
Add-BitLockerKeyProtector -MountPoint "C:" -TpmAndPinProtector `
  -Pin (ConvertTo-SecureString $pin -AsPlainText -Force)

# Find and remove the bare TPM-only protector
$tpmOnly = (Get-BitLockerVolume -MountPoint "C:").KeyProtector |
  Where-Object { $_.KeyProtectorType -eq 'Tpm' }
Remove-BitLockerKeyProtector -MountPoint "C:" -KeyProtectorId $tpmOnly.KeyProtectorId

Order matters here. Confirm the Add succeeded before you run the Remove. If the script dies between the two, the device keeps both protectors, and a device that still has a bare Tpm protector boots without a PIN no matter what else is on it. Re-read the protector set after ((Get-BitLockerVolume -MountPoint "C:").KeyProtector) and confirm Tpm is gone and TpmPin is present. That check is what “done” looks like on this step.

You still own the PIN-collection UX. Community remediation scripts put a WPF prompt in front of the user to capture the PIN value before calling Add-BitLockerKeyProtector. Make sure recovery-key escrow to Entra is on before this runs, because a forgotten PIN turns into a recovery-key flow immediately.

How to verify at scale

This is the part most rollouts skip, and it’s the only part that turns “pushed” into “proven.” Use Intune custom compliance: a PowerShell discovery script plus a JSON rules file. The script emits one line of compressed JSON; its hashtable keys become setting names. The JSON rules file evaluates those settings.

Detection logic: protection is on and a TPM+PIN protector exists. Get-BitLockerVolume exposes .KeyProtector[].KeyProtectorType; the value for TPM+PIN is the string "TpmPin". (The WMI equivalent, Win32_EncryptableVolume.GetKeyProtectorType, returns integer 4 = “TPM And PIN,” which is officially documented; the "TpmPin" string is consistent across practitioner sources but not enumerated on a single Microsoft page, so run (Get-BitLockerVolume).KeyProtector.KeyProtectorType on a known-good device first.)

Discovery script:

# Intune: set "Run script in 64-bit PowerShell Host" = Yes (BitLocker module is 64-bit only).
# Runs as SYSTEM by default, which is correct.
$bl = Get-BitLockerVolume -MountPoint $env:SystemDrive
$protectionOn = ($bl.ProtectionStatus -eq "On")
$hasTpmPin = ($bl.KeyProtector | Where-Object { $_.KeyProtectorType -eq "TpmPin" }) -ne $null
$hash = @{ BitLockerProtectionOn = $protectionOn; TpmPinProtectorPresent = $hasTpmPin }
return $hash | ConvertTo-Json -Compress

Expected output on a compliant device:

{"BitLockerProtectionOn":true,"TpmPinProtectorPresent":true}

JSON rules file. Setting names are case-sensitive and must match the hashtable keys exactly:

{
  "Rules": [
    {
      "SettingName": "BitLockerProtectionOn",
      "Operator": "IsEquals",
      "DataType": "Boolean",
      "Operand": true,
      "MoreInfoUrl": "https://patchdayalert.com",
      "RemediationStrings": [
        {
          "Language": "en_US",
          "Title": "BitLocker is not protecting the OS drive",
          "Description": "Enable BitLocker on the system drive."
        }
      ]
    },
    {
      "SettingName": "TpmPinProtectorPresent",
      "Operator": "IsEquals",
      "DataType": "Boolean",
      "Operand": true,
      "MoreInfoUrl": "https://patchdayalert.com",
      "RemediationStrings": [
        {
          "Language": "en_US",
          "Title": "No TPM+PIN protector found",
          "Description": "This device boots without a startup PIN. Add a TPM+PIN protector to mitigate CVE-2026-45585."
        }
      ]
    }
  ]
}

Both rules must pass. A device with BitLocker on but only a plain TPM protector fails on TpmPinProtectorPresent. That’s exactly the YellowKey-exposed state, and it’s the device the bare “PIN required” toggle never touched.

This is also how you find your TPM-only devices: deploy the compliance policy fleet-wide and read the non-compliant list. The machines failing TpmPinProtectorPresent are your remediation queue.

Gotchas that will eat your afternoon:

• 64-bit host is mandatory. The BitLocker module won’t load in the default 32-bit host and returns empty or garbage. Set “Run script in 64-bit PowerShell Host” = Yes.
• Keep output tiny. The official limit is 1 MB, but practitioners report a roughly 2048-character practical ceiling (community-reported, not in current Microsoft docs); overflow truncates the JSON and throws error 65009. The two-key output above is nowhere near it, but don’t bloat the script.
• Error codes: 65007 script failed, 65008 a setting is missing from output, 65009 invalid JSON, 65010 datatype mismatch.
• Evaluation runs on roughly an 8-hour cadence with no push-to-evaluate. A device you remediate can take that long to flip to compliant. Budget for it before someone asks why the dashboard is still red.
• One script per policy, one policy per script. Bundle related checks into a single script/rule pair.

When to escalate

Some devices can’t take a PIN cleanly, and forcing one creates a worse problem than YellowKey:

• Unattended-reboot machines. A TPM+PIN device that auto-reboots for patching sits dead at the PIN prompt until someone walks over. Microsoft’s answer is BitLocker Network Unlock (UEFI DHCP + WDS + PKI, wired only), which is real infrastructure most Intune shops have already torn down. For servers and kiosks behind physical controls, TPM-only is often the sane exclusion.
• Slates without an attached keyboard. They need the preboot-input-on-slates setting and a physically connected keyboard at boot.
• HSTI / Modern Standby devices that the CSP can’t configure. These need the manual or Win32-app path, not the policy toggle.
• TPM lockout. Repeated wrong PINs trigger anti-hammering. The recovery key unlocks the volume but does not reset the lockout timer. Tell users to stop after 3-4 tries; lockout behavior varies by manufacturer.

One caveat to carry forward: TPM+PIN defeats the public PoC, not necessarily YellowKey forever. Eclypsium reports the researcher claims a PIN-defeating variant exists but withheld it; that’s unverified, and there’s no Microsoft patch ETA as of late May 2026. Treat the PIN as today’s mitigation, not the close-out.

Requiring a control and proving it are two different jobs. The toggle is a statement of intent; the compliance policy is the evidence. Build the evidence first, and “we require TPM+PIN” stops being a hope and becomes a number you can read off a dashboard. PatchDay Alert covers the bypasses that make controls like this worth proving, not just the patch that eventually closes them.
